Note: the Windows Firewall may block some of the ports used by Zetafax Server. Start Zetafax Server either from the Start menu to run as an application or from Services.

Save the settings and finish the wizard.

Please note that it is disabled by default.

Select the user to receive incoming faxes from the drop down.

This is the IP and the port of the Zetafax Server.

Specify the Local Address and the port.

This is the IP and the port of the DMG (In this example: IP 10.12.13.74 port 5060).

You will need to specify the Gateway IP and the port.

#Dialogic dmg 1000 Patch#

If you not see these options please follow the steps in the “Install the FoIP patch for Zetafax” section of this guide. Please select “Dialogic DMG 1000” in the Gateway type.Add the FoIP device in Zetafax Configuration Note that that this is only done once per Zetafax Server.Ī patch is available to enable support for Dialogic Media Gateway.

#Dialogic dmg 1000 registration#

Right click on Licensing and Registration and follow the wizard to add the license.Open Zetafax Configuration from the Start menu.

#Dialogic dmg 1000 license#

Now the DMG should be setup to be used with Zetafax.Īdd the Zetafax Standard FoIP connector add-on license in Zetafax Configuration

Apply the settings pressing on the submit button.

Set the outbound destination to TDM and Trunk group to the one you created earlier (or the one that has been created by default).

This time we need to configure an Inbound VoIP Rule. Make sure VoIP is the outbound destination and the host group you had setup is selected. Step 3 – Click on Inbound TDM Rules at the top, and scroll down to the Outbound Routes section. Be sure to click on Submit otherwise the Host List will remain red and will not function. Step 2 – Enter the IP of the Zetafax Server into the Host List box. You only need one host group as there is only one destination.

Step 1 - Click on VoIP Host Groups at the top. Before you set up the Outbound Route, you must set up a VoIP Host Group. This route will be directed over VoIP to the FoIP (Zetafax Server) machine. Once you have selected a trunk group for an Inbound TDM Rule, you must define an outbound route. For a basic setup you can leave this as the default (set to *), which groups all Analogue channels into one trunk group. TDM Trunk Groups – you can group different channels together in this section. Inbound TDM Rules – this is the rule which defines where TDM calls are routed. Inbound faxing consists of two parts – Inbound TDM Rules and TDM Trunk Groups. When you see TDM anywhere in the configuration, this is referring to the PSTN signal.

We need to tell the DMG to take a PSTN call and forward it to the Zetafax Server machine, and to talk on a specific protocol (SIP) so that FoIP can understand it. In a Zetafax environment we look at inbound faxes as being PSTN > IP. This section is all about defining how the DMG should respond to calls when coming through via PSTN and IP.

Routing: Configure Zetafax to talk to DMG

Click on Submit and then you will need to restart the DMG.

Once the configuration screen has loaded up, you can change IP settings by clicking on IP under the Configuration section.

The default browser URL of the DMG is with username: admin and password: IpodAdmin.

This document will only cover the web interface.

#Dialogic dmg 1000 serial#

You can access the configuration screen of the DMG via Web Interface or Serial connection. So therefore you must first configure the IP settings. The DMG must be reachable by the Zetafax Server over the network. The concept of configuring the DMG falls into two main points: the ability to send and receive faxes.įull documentation for the DMG can be found here. While the DMG offers many configurable options, this document will only cover a basic configuration i.e. The DMG is basically the gateway where PSTN is converted to IP and vice versa.

Add the Zetafax Standard FoIP connector add-on license in Zetafax Configuration.

Routing: Configure Zetafax to talk to DMG.

The configuration procedure will consist of the following steps:

Dialogic Media Gateway 1000 (known as DMG from here onwards).

Zetafax Standard FoIP connector license.

More informationĪssuming that this is a fresh Zetafax installation prior to setting up FoIP: This document will take you through the steps to get a basic setup of Fax over IP in Zetafax using Standard FoIP and Dialogic Media Gateway (the 1000 analog model specifically in this document).
